    528gpm Drilling Mud Equipment Waste Management Dry Shaker

    Ask Lasest Price
    Brand Name : AIPU Solids
    Model Number : Drying shaker
    Certification : API, ISO
    Price : USD15950~20290/Set
    Payment Terms : L/C, T/T
    Supply Ability : 30 sets per month
    Delivery Time : 7 days
    • Product Details
    • Company Profile

    528gpm Drilling Mud Equipment Waste Management Dry Shaker

    Dry shaker used in drilling fluids process or the waste management


    AIPU Hunter series shale shaker are high quality product and appreciated by all of clients. High efficiency and relaible enough. The drying shaker containing the all features and benefits of AIPU common shaker. The difference between drying shaker and common Hunter shaker is the motor and the vibration strength or the centrifugal force produced by vibration motors. Shale shaker is high quality equipment for drilling mud process. Considering the drying fuction on drilling fluids and waste, the vibration mode is linear motion. It is widely used in oil and gas drilling, for waste management for the sludge treatment. The shaker is driven by 2 same power vibration more provide efficient productivity. Its main structure is shaker basket, base, feeder box, screen panel, motor, control panel, buffering spring


     drying shaker for drilling fluids


    Detail of AIPU Drying shaker


    Please find below information of AIPU dry shaker specification


    Hunter-D3 shale shaker technical specification

    ModelHunter-HiG
    Vibrator Motor2.64HP x 2
    Max. Vibration Strength8.5G
    Treating Capacity528GPM
    Deck Angle-1~+5°(Customziable)
    GeneralScreen Panel Area2.73㎡
    Screen Panel Number4
    Weir Height760mm
    Ex MarkExd BT4 or customizable
    WeightAbout 1520kg

    Besides solids control, the shale shaker can be used to process the oil sludge or the waste management. The design on screen or deck may vary, but the main structure will be same. For some construction industry, such as HDD, piling, and tunnelling will request shaker and other equpment to process fluids. Hunter-HiG is an ideal equipment to help user get great solid-liquid separation result


    Hunter-HiG drying shaker is easy to operate and maintain. The screen panels are convenient to install and replce. We just need to knock out the wedge block and pull the panels out of deck, then put on the new panels to be used and put on the wedges there, knock them tight and ensure no loose. Thus screen will no move to deck or shaker basket user will get good performance.


    For the shaker motors, we use famous brand Oli or Martin. Some clients request higher configuration level. Then the motors will be Ital-Vibras imported from Italy. High quality motors will help much on stable performance and good result.


    The deck angle can be adjusted easily by just screw the nut on the jack screw. And angle should be adjusted according to actual working condition. For example, when we need high flow rate we need to make deck with small minus angle or in parallel to ground. If we need better filtration or more dry solids, plese make deck with uphill angle. The rotation can be clock wise or anti-clock wise


    Moreover, clients will use AIPU shaker to process the slurry or some high water content mixture of sand and water, etc. The Hunter-HiG shaker will help much to save the economy benefits and the time benefits for clients.


    Based on different requirements of job site the drying shaker can be made as dual tandem and the triple tandem, too. The G force of the motor can be adjusted according to practical demand. It's easy to achieve. The higher vibration strength will lead less flow rate but the better drying effect and the better performance.


    Please feel free to contact AIPU Solids control. Get free offer now!
